ZHIYUN Smooth-C - Multi-Function 3 Axis Handheld Stabilizer (for Smartphones)
ZHIYUN Smooth-C
Highlights
No Blur On the Move
Empowered by the advanced stabilizing technology, SMOOTH-C presents you a whole new way to record videos and take photos with your smartphone camera. No matter how your hands tend to shake or how you rush or move when trying to capture a shot, SMOOTH-C will keep the camera still and steady to help you create wonderful smooth streams with cinematic effect that are ready to share.
3rd Generation Motor Control System
Empowered by ZHIYUN’s 3rd Generation Motor Control System with enhanced motor performance by 30%, SMOOTH-C responses to intense motions or even sudden twists in real-time with precise and smooth compensation to help you create perfect video streams even when you move.
Faster Speed with Lower Consumption
Well-tuned by ZHIYUN’s self-innovated Instune 3.0 Algorithm, the work efficiency of control motors on all three axes of SMOOTH-C has been greatly improved, thus reducing power consumption during operations with faster and more accurate stabilizing performance.
Smart Control for Free Creativity
Integrated with the world’s leading stabilizing technology in ZHIYUN’s unique high-precision motor control system, combined with the 3 classic smart gimbal mode for easiest control, SMOOTH-C offers PAN FOLLOWING, LOCKING and FOLLOWING MODE options to help you create with more convenience and freedom.
Battery Extension Design
SMOOTH-C comes standard with two 18350 Li-Ion batteries installed in a highly portable and compact construction, supporting a 4-hour continuous runtime. Meanwhile, as SMOOTH-C is also compatible with 18650 batteries, it allows an alternate battery option for extended working time up to 6 hours with an extensional battery compartment for convenient installation.
Tech Specs
| Item | Min. | Standard | Max. | Remark |
| Operation Voltage | 6.8V | 8.4 | 12.6V | |
| Operation Current | 50mA | 120mA | 2000mA | |
| Following Deviation in Static State | ±0.01° | ±0.04° | ||
| Following Deviation in Motion State | ±0.01° | ±0.02° | ±0.5° | |
| Tilt Angle Range | 320° | |||
| Roll Angle Range | 270° | |||
| Pan Angle Range | 320° | |||
| Controllable Tilt Angle | -135° | +185° | ||
| Controllable Roll Angle | -30° | +30° | ||
| Controllable Pan Angle | -160° | +160° | ||
| Operation Temperature | -10°C | 25°C | 45°C | |
| Battery Runtime | 3h | 4h | 5h | |
| Charging Time | 2h | |||
| Valid Payload | ||||
| Compatible Cameras | Smartphones with size under 6.0" |
Packing List |
||||
| Item | Qty. | |||
| Gimbal Stabilizer | 1 | |||
| Camera Protection Sticker for Pan Axis Motor | 1 | |||
| Counterweight | 1 | |||
| 18350 Battery Charger | 1 | |||
| 18350 Li-ion Batteries | 2 | |||
| Micro USB Cable | 1 | |||
| User Guide | 1 | |||
| Warranty Card | 1 | |||
| Company Contact Card | 1 | |||
Packing Specifications |
||||
| Item | Dim./Weight | Remark | ||
| Product Dimension | 103*104*288mm | W*D*H | ||
| Package Size | 317*157*55mm | L*W*H | ||
| Carton Size (Dedicated) | 375*370*320mm | L*W*H | ||
| Product Net Weight | 350g/Unit | |||
| Gross Weight (including package) | 950g/Unit | |||
| Packing Weight | 11kg/Carton | 10 Units/Carton | ||
